Autel VW 360 AVM System Pattern Package
Couldn't load pickup availability
Autel VW 360 AVM System Pattern Package (CSC1004-01)
The Autel CSC1004-01 is an Around View Monitor (AVM) calibration pattern package for Volkswagen vehicles. This pattern package is used with an Autel ADAS calibration system to perform static calibration of VW 360-degree surround view camera systems after windshield replacement, camera repositioning, or any service that disturbs the factory camera alignment.
What AVM Calibration Requires
360-degree surround view systems stitch together feeds from multiple cameras — typically front, rear, and both sides. When any of those cameras are disturbed (via body work, glass replacement, or sensor service), the system loses its calibration and the stitched image distorts. Proper static AVM calibration using manufacturer-specified target patterns restores the system to OEM spec and clears any associated DTCs.
Application
- Vehicle make: Volkswagen
- System: 360-degree Around View Monitor (AVM) surround view cameras
- Calibration type: Static (performed in the bay with pattern targets)
- Compatible with: Autel ADAS calibration systems (verify compatibility with your specific frame/tablet)
- Price: $845
Who Needs This Package
Any shop performing glass replacement, front-end work, or camera-related repairs on VW models equipped with 360 AVM will need this pattern set to complete the calibration properly. Selling the repair without the calibration is incomplete — and increasingly, insurance work requires documented ADAS calibration.
Note: Detailed specifications and full system compatibility were not available from the manufacturer page at time of writing. Call us to confirm fitment with your existing Autel ADAS frame before ordering.
Why Buy the Autel VW 360 AVM System Pattern Package From Autel Diagnostic Tools?
Autel Diagnostic Tools has specialized in ADAS calibration equipment since 2016. We carry the full Autel ADAS pattern and target library and can verify exactly which packages your system needs for VW AVM work. Free shipping. Tech support at 866-217-0063. Full warranty honored.
Call 866-217-0063 for quick answers and help!
Specifications
Specifications
Detailed specifications are included in the product description above. For complete technical specs, vehicle coverage lists, or comparison help, call our team at 866-217-0063.
We can look up specific vehicle coverage for any Autel tool in seconds.
Shipping & Returns
Shipping & Returns
Free standard shipping on every order within the continental United States. Most orders ship within 1-2 business days via UPS or FedEx.
Returns: 30-day return policy on unused items in original packaging. Contact us at 866-217-0063 or email to start a return. Restocking fees may apply to opened items.
See our full Shipping & Returns Policy for details.
Warranty
Warranty
All Autel tools come with the manufacturer's standard warranty, typically 1 year from date of purchase. Warranty covers defects in materials and workmanship.
Total Care Program (TCP): Autel offers an annual software update subscription. Your first year of updates is included with purchase. After Year 1, renew through Autel's TCP program to keep receiving the latest vehicle coverage and features.
Questions about warranty or TCP? Call us at 866-217-0063.
Software Updates
Software Updates
First year of software updates included with every Autel diagnostic tool purchase.
Autel releases regular updates that add new vehicle coverage, fix bugs, and unlock new diagnostic functions. Updates are downloaded via Wi-Fi directly on your tool or through the Autel MaxiPC Suite software.
After Year 1: Renew your subscription through Autel's Total Care Program (TCP). Pricing varies by model. We can help you find the right TCP card for your tool.
Browse TCP Cards & Software Updates or call 866-217-0063 for help.
