Autel TS508WFK-1 Kit: TS508WF Tool, (8) 1-Sensors

Autel TS508WFK-1 Kit — TS508WF Tool with 8 MX-Sensors (1-Sensors)

The TS508WFK-1 is a value kit that bundles the Autel TS508WF TPMS service tool with eight MX-Sensors (1-Sensors). If you are setting up TPMS service capability at your shop and want to start with a stock of programmable sensors alongside the tool, this kit saves you from ordering them separately. At $419.95, you are getting the TS508WF tool plus eight sensors that retail at $39.95 each ($319.60 in sensors alone) for a meaningful combined discount versus buying individually.

The TS508WF Tool

The TS508WF is Autel's advanced handheld TPMS service tool with Wi-Fi update capability. It handles the full range of TPMS service work:

• Read, activate, and relearn all known TPMS sensors (OEM and aftermarket)
• Detect and display TPMS system faults
• On-screen vehicle-specific relearn procedures with OBDII relearn support
• TPMS Status Screen: read ECU sensor IDs, check sensor/ECU ID matching, read/erase DTCs
• Placard value reset on supported vehicles
• Key fob signal test
• Two service modes: Quick Mode (fast sensor check and programming) and Advanced Mode (full diagnostics, relearn, and sensor position management)
• Two MX-Sensor programming methods

Wi-Fi Updates Included

The "WF" model updates via Wi-Fi (no computer required) or USB. Software updates are free for the life of the tool. Autel recommends updating every 2-3 weeks to stay current on vehicle coverage.

The Eight Included MX-Sensors (1-Sensors)

Autel's MX-Sensor — also called the 1-Sensor — is a universal programmable TPMS sensor designed to replace 99.7% of OEM TPMS sensors. Key specs:

• Frequencies: Dual 315MHz and 433MHz — covers both US and European frequency requirements in one sensor
• Valve stems: Comes with rubber press-in valve stems; the press-release button design lets you swap in aluminum valve stems (sold separately) without replacing the sensor body
• Programmability: Program once to replace the OEM sensor, or copy-by-activation from the original sensor if it still reads
• SAE compliance: Meets SAE standards J1205 and J1206
• Warranty: 2-year limited warranty on sensors

Eight sensors cover a full set of four wheels for two vehicles — a practical starting inventory for a shop setting up TPMS service for the first time or restocking.

TS508WF Specifications

• Display: 2.3-inch TFT color, 320×240 resolution
• Battery: 3.7V lithium-polymer, 3,200 mAh
• Dimensions: 215mm × 105mm × 37mm (8.46" × 4.13" × 1.46")
• Weight: 0.39 kg (0.86 lb)
• Operating Temperature: 0°C to 50°C (32°F to 122°F)
• Warranty: 1-year limited on tool / 2-year on sensors

What Is Included

• Autel TS508WF handheld TPMS tool
• OBDII cable
• Eight MX-Sensor 1-Sensors (rubber valve stem)

Is This Kit Right for Your Shop?

The TS508WFK-1 makes sense for a shop that wants to start doing TPMS sensor replacements, not just relearns. If you only need to relearn sensors after tire rotations and you already have all OEM sensors, the standalone TS508WF (SKU 700010) is sufficient. If you want to stock a universal replacement sensor that programs with the tool, this kit is the efficient way to get started.
