Autel MaxiIM IKEY IKEYAT5TPR

Autel MaxiIM IKEY IKEYAT5TPR — 5-Button Universal Key for Minivans with Dual Power Sliding Doors

The IKEYAT5TPR is the minivan-specific configuration in Autel's MaxiIM IKEY lineup. What makes this key different from every other IKEY on the shelf is that it includes dedicated Left Sliding Door and Right Sliding Door buttons. If a customer's minivan has power sliding doors on both sides — think Chrysler Pacifica, Dodge Grand Caravan, Kia Sedona, or Honda Odyssey — and they need a replacement remote, this is the key that matches their original functionality.

This SKU is listed as a 5-button key, with Lock and Unlock treated as a single grouped function, giving six distinct button actions in total. That distinction matters when matching against OEM part numbers.

Button Layout

• Lock — Arms the vehicle and flashes the lights
• Unlock — Disarms the system and opens doors per factory setting
• Remote Start — Pre-conditions the cabin for heat or cooling before the driver gets in
• Left Sliding Door — Opens or closes the driver-side power sliding door remotely
• Right Sliding Door — Opens or closes the passenger-side power sliding door remotely
• Panic — Triggers the horn and lights for emergency or security use

Who Needs This Specific Key?

Minivan owners use the sliding door buttons constantly — loading groceries, dropping kids off, unloading from a wheelchair ramp. When the original remote is lost or damaged, a standard IKEY without the sliding door buttons is a significant downgrade in daily functionality. The IKEYAT5TPR is the only IKEY configuration that gives them back both sliding door controls plus Remote Start and Panic.

This key is the right call for shops that regularly service Chrysler/Dodge/RAM minivans, Kia Carnival and Sedona, Honda Odyssey, or Toyota Sienna models that came with factory dual power sliding doors and Remote Start.

Technical Specifications

• Frequency: 315 MHz / 415 MHz (dual-frequency, auto-detected during programming)
• Range: Up to 40 meters / 130 feet line-of-sight
• Required Programmer: Autel KM100 (sold separately)
• Battery: CR2032 coin cell — not included, available at any hardware or drug store
• Emergency Mechanical Blade: Not included — order the appropriate blade for the vehicle make separately if needed

Compatible Vehicle Makes

The IKEY platform is designed as a universal aftermarket solution. The IKEYAT5TPR has been validated for use with vehicles from:

• Hyundai
• Nissan
• Chrysler (FCA group — including Dodge Grand Caravan and Chrysler Pacifica)
• Honda
• GM (Chevrolet, Buick, GMC, Cadillac)
• Select BMW, Audi, Volkswagen, and Volvo models

Always cross-reference the original remote and the Autel IKEY compatibility chart before ordering. The KM100 will confirm a valid pairing before writing the key.

Programming Overview

The IKEYAT5TPR programs using the Autel KM100. Connect the KM100 to the OBD-II port, select the make, model, and year, and follow the on-screen steps. The process does not require dealer tools or a dealership visit. Most experienced technicians complete the programming in under 15 minutes. If you have questions before or during the job, our tech support line at 866-217-0063 is available.

What Is Not Included

• CR2032 Battery: Not included. Pick one up at any hardware store, pharmacy, or grocery store.
• Emergency Blade: Not included. Order the vehicle-specific mechanical blade separately if the customer needs manual entry capability.

IKEYAT5TPR vs. Other IKEYs — Make the Right Call

The dual sliding door buttons make this the only IKEY built for full-size minivan service. A quick comparison:

• IKEYAT5PCE — Lock, Unlock, EV Charge, Remote Start, Panic
• IKEYAT5PRA — Lock, Unlock, Air Suspension, Remote Start, Panic
• IKEYAT5PS — Lock, Unlock, Air Suspension, Panic (no Remote Start)
• IKEYAT5TPR — Lock, Unlock, Remote Start, Left Sliding Door, Right Sliding Door, Panic (this key)

No other IKEY SKU covers both sliding doors. If the original minivan remote had individual left and right door buttons, the IKEYAT5TPR is the only replacement that matches it.
