Autel MaxiIM IKEY IKEYAT5PRA

Autel MaxiIM IKEY IKEYAT5PRA — 5-Button Universal Key with Air Suspension Button

The IKEYAT5PRA is the air suspension variant in Autel's MaxiIM IKEY lineup. It shares the same universal platform and KM100 programming process as every other IKEY, but this configuration adds a dedicated Air Suspension button alongside Remote Start. That combination targets a specific group of vehicles — primarily trucks, SUVs, and luxury cars with factory air suspension systems that allow the driver to raise or lower the chassis from outside the vehicle before getting in.

Button Layout

• Lock — Arms the vehicle and flashes the lights
• Unlock — Disarms the system and opens doors per factory setting
• Air Suspension — Adjusts the vehicle's air suspension height remotely; used on trucks for towing/hauling prep and on luxury SUVs for entry/exit ease
• Remote Start — Pre-conditions the cabin for heat or cooling before the driver gets in
• Panic — Triggers the horn and lights for emergency or security use

Who Needs This Specific Key?

The air suspension button is a niche but important function. If a customer drives a vehicle with a factory air suspension system — think Ram 1500 with the air bag option, Lincoln Navigator, Cadillac Escalade, or select Land Rover models — and that vehicle's original remote had an air suspension button on it, this is the replacement key. Using a standard 4-button IKEY or the wrong 5-button SKU will leave the customer unable to operate the suspension remotely. The IKEYAT5PRA also includes Remote Start, which is the other distinction from the IKEYAT5PS (same air suspension button, but no Remote Start).

Technical Specifications

• Frequency: 315 MHz / 415 MHz (dual-frequency, auto-detected during programming)
• Range: Up to 40 meters / 130 feet line-of-sight
• Required Programmer: Autel KM100 (sold separately)
• Battery: CR2032 coin cell — not included, available at any hardware or drug store
• Emergency Mechanical Blade: Not included — order the appropriate blade for the vehicle make separately if needed

Compatible Vehicle Makes

The IKEY platform is designed as a universal aftermarket solution. The IKEYAT5PRA has been validated for use with vehicles from:

• Hyundai
• Nissan
• Chrysler (FCA group)
• Honda
• GM (Chevrolet, Buick, GMC, Cadillac)
• Select BMW, Audi, Volkswagen, and Volvo models

Always cross-reference the original remote's button layout and the Autel IKEY compatibility chart before ordering. The KM100 programmer will confirm a pairing match before writing the key.

Programming Overview

The IKEYAT5PRA programs using the Autel KM100. Connect the KM100 to the vehicle's OBD-II port, select the make and model, and follow the on-screen instructions to write the key. Most experienced technicians complete the process in under 15 minutes. No dealership equipment required. Questions? Call our tech support team at 866-217-0063 before you start the job.

What Is Not Included

• CR2032 Battery: Not included. Available at most drug stores, grocery stores, and hardware stores.
• Emergency Blade: Not included. Order the vehicle-specific mechanical blade separately if the customer needs a manual entry option.

IKEYAT5PRA vs. Other IKEYs — Make the Right Call

The five 5-button IKEY SKUs are distinguished by that third button. Getting the right one matters:

• IKEYAT5PCE — Lock, Unlock, EV Charge, Remote Start, Panic
• IKEYAT5PRA — Lock, Unlock, Air Suspension, Remote Start, Panic (this key)
• IKEYAT5PS — Lock, Unlock, Air Suspension, Panic (no Remote Start)
• IKEYAT5TPR — Lock, Unlock, Remote Start, Left Sliding Door, Right Sliding Door, Panic

The difference between IKEYAT5PRA and IKEYAT5PS is Remote Start. If the customer's original key had Remote Start and Air Suspension, order the IKEYAT5PRA. If it only had Air Suspension without Remote Start, order the IKEYAT5PS. Match what the customer walked in with.
